SVS SoundPath Speaker Level Subwoofer Adapter
€ 110,00
Add pristine speaker-level subwoofer connectivity to line-level subwoofers without loss of fidelity. For use with integrated amplifiers and older stereo receivers that do not have line level or subwoofer outputs.
Introduction
Easily connect a subwoofer to older audio components
Many integrated amplifiers and older stereo receivers do not have line-level outputs, preventing enthusiasts from connecting an active subwoofer to their system.
The SVS SoundPath Speaker Level Subwoofer Adapter elegantly solves this problem by reducing the speaker amplifier voltage at speaker level to RCA voltage at line level, allowing safe connection to a subwoofer without loss of quality.
With a minimalist design and premium components, the SoundPath Speaker Level Subwoofer Adapter provides pristine and transparent signal transfer to the subwoofer without disturbing any part of the playback system.
SVS SoundPath Bi-wire Speaker Cable can be used for easy and elegant connection to both the speaker amplifier and the SoundPath Speaker-Level to Line-Level adapter.
Features
- Stereo Gold-plated 5-way speaker connectors for bare wire, spade or banana.
- Gold-plated stereo RCA line-level output jacks provide a secure connection to the line-level inputs of the active subwoofer. Works seamlessly with a pair of SVS SoundPath RCA subwoofer cables.
- Features high-quality narrow-tolerance resistors and wide-track PCBs for high current and extreme load capacity. Uncompromised design ensures wide bandwidth and ultra-low distortion for pristine signal transmission, hair-trigger accuracy and compatibility with all high-end audio systems.
- -30 dBV attenuation does not drain power from the speaker amplifier, ensuring a safe signal for the subwoofer’s line inputs.
- Minimalist design with insulated chassis for discreet placement.
Technical specifications
- Speaker inputs: Stereo gold-plated 5-way speaker jacks
- Line level outputs: Stereo gold-plated RCA Jacks
- Speaker-Level Input Impedance: 4.85 kΩ
- Line level output impedance: 150 Ω
- Voltage attenuation: -30 dBV
- Power: 500 W RMS / 1,000 W Peak
- Frequency range: 10 Hz – 80 kHz (+/- 0.01 dB)
- THD+N @ 10V: <0.03% (10 Hz – 80 kHz)
- Dimensions: 37 mm H x 99 mm W x 103 m D
- Weight: 0.28 kg.
| Weight | 0,3 kg |
|---|---|
| Dimensions | 14 × 15 × 6 cm |
